SIMRAD TP22 Tillerpilot
SIMRAD TP22 Tillerpilot is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
-
BrandSimrad
-
SKU:TP22
-
Barcode:
Description
Description
For Yachts up to 36ft. - Simrad Tillerpilots are designed for high precision, reliable auto-steering while drawing low current to optimize battery life High performance for small to mid range sailboats Simrad Tillerpilots are designed for high precision, reliable auto-steering while drawing low current to optimize battery life. The hard wearing, waterproof body contains all controls and has been tested for many hours in total immersion. Exceptionally quiet in use, the Tillerpilot gives fast and positive performance for effective steering in a wide range of sea states and wind conditions. A range of pilots offers performance to suit most small to medium sailboats. The Simrad TP22 and Sirmad TP32 Tiller pilots offer easy interfacing to external devices using Simrad's proprietary network system, SimNet. When interfaced, enhanced options such as sail to wind or sail to waypoint are easily accessed via the key pad. The recommendations assume typical coastal sailing conditions and in circumstances where extended voyages or more extreme weather conditions are expected, the choice of a higher specification pilot is recommended including the full range of Simrad below deck pilots.
- Waterproof sealing for protection of the elements and reliable use
- Extremely quiet, enjoy the silence of sailing
- SimNet compatible, simple plug and play DIY installation (TP22 and TP32)
- Easy operation
Autopilot / Autosteering
- Peak Thrust 70kg
- Max Boat Displacement 5 tons
- Max Boat Length 11 m 36 ft
- Drive System Screw Thread
- Intelligent Steering Action Yes
- Fluxgate Compass Yes
- Mounting Selectable Port Or Starboard Yes
- Steer To GPS Yes
- Steer To Wind Yes
Network / Connectors
- NMEA 0183 Input Yes
- SimNet Control Yes
Power
- Power Supply 12Vdc vDC
- Power Consumption Auto 0.05A
- Power Consumption Standby 0.06A
Other
- Adjustable Gain Yes
- Alarm: Audible and Visible Yes
- Auto Seastate Yes
- Auto Trim Yes
- Automatic Tracking Yes
- Gain 1-9
- Night Illumination Yes
- Non Volatile Memory Yes
- Operating Temperature -10 degree to +55 degree
- Operating Temperature Stored -10 degree to +55 degree
- Remote Control Option Yes
- Storm Proof Yes
