Muir Compact HR950 Windlass
Muir Compact HR950 Windlass - with Capstan is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Muir Vertical Windlass – 750W 12V for 7–11m Vessels
Built for power and performance, this Muir vertical windlass is engineered to handle demanding anchoring needs on vessels between 7–11 meters. Featuring a robust 750W dual-direction marine-grade motor and a superior Italian heavy-duty drive train, it delivers reliable lifting power with a maximum load capacity of 464kg and a line speed of up to 21 meters per minute.
Crafted with a brushed 316 stainless steel housing and polished stainless steel components, it’s built to withstand the harshest marine conditions. The unit supports multiple global chain standards, fits 8mm (5/16”) chain, and accommodates 12mm to 16mm rope sizes. It also features independent gypsy and capstan operation, chain pipe and peeler, and is Auto Anchor compatible.
Key Features:
-
High-tensile stainless steel shaft
-
Deck isolation pad for vibration dampening
-
Brushed finish and polished stainless steel construction
-
Front double twin footings for enhanced deck stability
-
Operates on 12V DC with an 80A Muir circuit breaker recommendation
-
Weighs just 13kg
Perfect for serious boaters looking for performance, durability, and ease of integration.
-
BrandMuir
-
SKUMUI-HR950-12
-
Typewinch
-
Control technologyMotorized
-
Durability featuresRustproof, Weather resistant
-
Item materialStainless steel
-
Power sourceDC-powered
-
Watercraft typeBoat, Sailboat, Yacht
-
Windlass designHorizontal, Vertical
-
Barcode910000080653
